PF 52

The PF 52 surface planer meets the requirements of carpenters and the most demanding companies.

Advantages

Reliability: The worktables can be adjusted by means of parallelogram shaped connecting rods which allow perfect parallel adjustment of the tables and guarantees a constant distance between these and the cutter block, at any cutting depth. This solution eliminates machining defects caused by vibrations, even with heavy stock removal.
Flexibility: The very long, ribbed, cast iron worktables allow perfect straightening of very long parts. Tiltable planing fence for any type of machining.
Ergonomics: Ergonomically positioned control panel at the front of the machine, easily accessible by the operator.

Technical data
  PF 520
Total length of surface tables 2750 mm
Useful working width 520 mm
Max. stock removal 8 mm
Planing fence tiltable 90°÷45° 1200 x 190 mm
Cutter block diameter 120 mm
no. knives 4
Motor power at 50 Hz  5 kW / 7 Hp
Motor power at 60 Hz  6 kW / 8 Hp
Documentation
Plus_IT_ES Download
Plus_EN_FR Download
PLUS_EN_DE Download
